Technical Specifications:

Design Standard: API6D

Face to Face Dimension Standard: ANSI B16.10

Flange Standard: ASME B16.5

Lining Material: PTFE, PFA, FEP

Temperature Range: PFA：-29℃-200℃， PTFE: -29℃-180℃，FEP:-29℃-150℃

Applicable Medium: Strong corrosive i.e.: hydrochloric acid, nitric acid, hydrofluoric acid, liquid chlorine, sulfuric acid and aqua regia etc.

Size Range: 1/2”-14” DN15-DN350

Pressure Range: 150Lb

Features:

Teflon lined ball valves have straight-through flow providing positive shutoff with minimal pressure drop and flow turbulence. With the ball independent of the stem, the ball has some freedom to move along the axis of the valve in the closed position, while having no freedom to rotate against the stem. When line pressure is applied to the closed ball, it moves slightly downstream to maintain contact with the downstream seat where primary sealing occurs.
